Description
Thompson manufacture their machines in strict accordance with Australian Standards & Regulations.
Thompson’s 2000 Series Mixer-Grinder is an efficient and powerful machine capable of a large throughput and a big mixing capacity (190 L bowl). The unit is fitted with two independent helical reduction motors which deliver quiet and continuous operation with minimal downtime.
- Helical Mince Drive for efficient discharge, minimising squashing and pulping of product.
- 304 Stainless Steel construction, including body, barrel, feed screw, lock ring and mixing paddle.
- Fully Seam Welded Bowl, welded inside and out for hygiene, with smooth corner design and surface finish.
- Ergonomic due to low loading height of 1069 mm.
- 24 V AC control circuit and full overload protection of motors.
| Product | 13 mm Hole Plate | 5 mm Hole Plate | 3 mm Hole Plate |
|---|---|---|---|
| Primary Cut – Beef Trim | 2000 kg/h | – | – |
| Secondary Cut – Ground Beef | – | 1400 kg/h | – |
| Secondary Cut – Sausage Mix | – | – | 1400 kg/h |
| Mince Motor | 5.5 kW |
|---|---|
| Mix Motor | 1.1 kW |
| Bowl Capacity | 190 L |
| Mix Capacity | 120 kg (fresh trim) |
| Power Supply | 20 Amp D Curve Circuit Breaker |
| Full Load Current | 14 Amps |
| Shipping Size | 1440L x 1140W x 1460H mm |
| Shipping Weight | 440 kg |
Technical data is subject to change without notice and should be a guide only.
